Surge Scientific · Model OH301 · Handheld Rotor-Stator Homogenizer
Handheld Rotor-Stator Homogenizer
160 W · 8,000–30,000 RPM · One-Handed
0.1 mL to 250 mL Sample Range · 10 Speed Levels · 316L SS Autoclavable Probes · Interchangeable 5/7/10 mm · 1.54 lb
The homogenizer that lives in your hand, not on a stand. The OH301 delivers 160 W of brushless DC torque at 8,000–30,000 RPM across 10 speed levels — enough shear force to lyse cells, homogenize soft tissue, and emulsify biological samples from 0.1 mL up to 250 mL depending on the probe you mount. 316L stainless steel generator probes (5 mm, 7 mm, or 10 mm) are fully autoclavable and interchangeable in seconds — one motor handles the full range from microtubes to beakers.
Why Rotor-Stator Is the Right Tool for Small-Batch Work
For the common lab homogenization task — lyse a cell pellet, break up a tissue sample, emulsify a 50 mL prep — the right tool isn't always a bead mill or a glass homogenizer. Bead mills are great for high-throughput plates but overkill for a single sample. Glass Dounce grinders preserve organelles but are slow and manual. Rotor-stator homogenization sits in the middle: fast, efficient, and scales from microtubes to 250 mL beakers by swapping the probe.
The mechanism is straightforward. The rotor spins inside a stationary stator at high RPM — up to 30,000 RPM, delivering 6.3–14 m/sec linear rotor speed. The gap between rotor and stator creates a suction effect that draws the sample through a narrow annular space, where it meets high shear forces that rupture cell walls, break up tissue structure, and create emulsions in seconds. The OH301 does this at 1.54 lb total weight — so it's comfortable for extended one-handed operation, or can sit in a stand for longer processing runs.
160 W · 30,000 RPM
160 W motor drives rotor speeds from 8,000 to 30,000 RPM across 10 speed levels. Handles viscosity up to 5,000 mPas — soft tissue, cell suspensions, emulsions, small-volume formulations.
0.1 mL to 250 mL Range
Three interchangeable probe sizes — 5 mm, 7 mm, 10 mm — cover the full volume range. 5 mm for microtubes (0.1–50 mL), 10 mm for beakers (1–250 mL). One motor, full versatility.
316L SS · Autoclavable
Probes made of 316L stainless steel — pharma-grade, corrosion-resistant, and fully autoclavable. Tool-free disassembly for thorough cleaning between sample types.
1.54 lb · One-Handed
Lightweight ergonomic design (1.54 lb) for comfortable extended one-handed operation. Also stand-compatible for longer runs. On/off switch lets speed stay dialed-in between uses.
"One motor. Three probes. From 0.1 mL microtubes to 250 mL beakers — no setup, no stand, no compromise." — The OH301 is what a rotor-stator should be: fast, versatile, and in your hand where it belongs.
Key Features
- 160 W brushless DC motor
- Variable speed 8,000–30,000 RPM
- 10 discrete speed levels
- Max linear rotor speed 6.3–14 m/sec
- Sample volume range 0.1 mL to 250 mL
- Max viscosity 5,000 mPas
- 316L stainless steel probes
- Fully autoclavable
- Corrosion-resistant construction
- Interchangeable probe design
- 5 mm probe (OH301P05) — 0.1–50 mL
- 7 mm probe (OH301P07)
- 10 mm probe (OH301P10) — 1–250 mL
- All probes 120 mm length
- Lightweight 1.54 lb (~700 g)
- Ergonomic one-handed design
- Stand-compatible mounting
- On/Off switch — speed stays dialed
- Max noise 72 dB(A)
- Operating environment 0–40°C
- Max humidity 85% rel.
- Ideal for cell lysis
- Ideal for tissue homogenization
- Ideal for emulsification
- Fast probe swap for sample-type changes
- Tool-free disassembly for cleaning
- 2-year all-inclusive warranty
Ideal Applications
Cell & Tissue Lysis
DNA/RNA extraction prep, protein analysis, enzyme activity assays, and general cell-disruption workflows from microtube to beaker scale.
Emulsification & Dispersion
Cosmetic emulsions, pharmaceutical formulations, small-scale industrial testing, and any workflow that needs stable emulsions in seconds.
Lab + Field Work
Portable design supports laboratory bench use and field sampling — take the OH301 to the sample when bringing the sample to the lab isn't an option.
What's in the Box
The OH301 ships with the standard 10 mm probe — 5 mm and 7 mm probes are available separately for smaller-volume applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model / SKU | OH301 |
| Motor Type | Brushless DC · 160 W |
| Speed Range | 8,000–30,000 RPM |
| Speed Levels | 10 discrete settings |
| Max Linear Rotor Speed | 6.3–14 m/sec |
| Sample Volume Range | 0.1 mL to 250 mL (probe dependent) |
| Max Viscosity | 5,000 mPas |
| Probe Material | 316L stainless steel — autoclavable |
| Probe Sizes Available | 5 mm (OH301P05), 7 mm (OH301P07), 10 mm (OH301P10) |
| Probe Length | 120 mm (all probes) |
| Weight | 1.54 lb (~700 g) |
| Operation Modes | Handheld or stand-mounted |
| Max Noise | 72 dB(A) |
| Operating Environment | 0–40°C · 85% relative humidity max |
| Control | Variable speed dial · On/Off switch |
| Warranty | 2-year all-inclusive |
Surge Scientific Warranty & Support
This instrument is sold through Surge Scientific, your trusted laboratory equipment partner. Our product specialists are available Monday–Friday for assistance. The OH301 is backed by a 2-year all-inclusive manufacturer's warranty. Contact us at info@surgescientific.com or reach out directly to our support team at 855.943.3344 for pre-sales questions, probe selection, stand accessories, and technical assistance.
