Surge Scientific · Model DBI100C
Heat / Cool Dry Block
Incubator
Active Cooling · Heating · Static Incubation · Ambient −15°C to 100°C · Interchangeable Blocks
Water baths require filling, emptying, and contamination management. Standard dry block incubators only heat. The DBI100C does neither — it heats and actively cools a dry aluminum block to Ambient −15°C using semiconductor Peltier technology, delivering precise static incubation across the full temperature range your protocols demand, without a drop of water or a separate cooling unit.
Static Incubation. Full Temperature Range.
Many laboratory protocols require precise temperature-controlled incubation without agitation — antibody binding, enzymatic digestion, cell lysis, sample preservation, and heat-inactivation steps where mixing would disrupt the reaction or the sample itself. Conventional dry block incubators cover these needs above ambient temperature, but fall short the moment a protocol calls for sub-ambient holding temperatures. Chilling samples on ice is imprecise. Transferring to a cold room interrupts workflow.
The DBI100C solves this with a single benchtop instrument. Its semiconductor cooling system drops the block to Ambient −15°C — cold enough for enzyme storage temperatures, cold-room substitution, and cryoprotectant steps — while the same microprocessor that controls cooling also maintains any temperature up to 100°C with ±0.2°C accuracy. One instrument, one footprint, the entire temperature range.
Active Semiconductor Cooling
Peltier semiconductor technology actively drives block temperature to Ambient −15°C — no ice, no cold room, no external chiller required. Cools to 4°C for enzyme-storage temperatures, or holds sub-ambient setpoints throughout long incubation windows without temperature drift.
Precision Temperature Control
Microprocessor control delivers ±0.2°C accuracy at 20–40°C and ±0.5°C uniformity across the block. Four programmable heating rates and four programmable cooling rates let you ramp between temperatures at controlled speeds — preventing thermal overshoot that denaturing or precipitates sensitive samples.
Programmable Multi-Step Sequences
Up to 5 sequential temperature steps with independent setpoints and hold times. Cycle up to 999 times. Pre-heating function warms the block to your target before samples are loaded. Power failure recovery resumes automatically from the last completed step — protecting unattended overnight protocols.
Dry Block — No Contamination Risk
Unlike water baths, the DBI100C uses direct aluminum block contact for heat transfer — no liquid medium, no cross-contamination, no evaporation, no daily cleaning of a water reservoir. Swappable aluminum alloy blocks auto-detected on installation support tube formats from 0.1mL to 50mL.
From 4°C enzyme storage to 95°C heat-inactivation — without moving the samples. Programme a multi-step sequence that holds at 4°C, ramps to 37°C for incubation, then climbs to 95°C for heat-inactivation, all in one unattended run. The DBI100C executes the full protocol in the same block the samples were loaded into at the start.
Key Features
- Active cooling: Ambient −15°C to 100°C full range
- Temperature accuracy: ±0.2°C at 20–40°C
- Temperature uniformity & stability: ±0.5°C
- Temperature resolution: 0.1°C
- Semiconductor Peltier cooling — no external chiller
- 7-inch color touchscreen with intuitive interface
- 4 programmable heating rates (Full Power / 5 / 2 / 1°C/min)
- 4 programmable cooling rates (Full Power / 2 / 1 / 0.5°C/min)
- Programmable up to 5-step sequences
- Cycle repeat up to 999 times
- Timer: 0–99hr 59min 59sec
- Pre-heating function for faster protocol starts
- Auto-resume after power failure
- 4-point calibration (10°C / 40°C / 70°C / 95°C)
- Interchangeable block modules with auto-detection
- Standard block: 24 × 1.5mL (included)
- Dry block — no liquid medium, no contamination risk
- Universal voltage: 110–220VAC, 50/60Hz
Compatible Block Modules
The DBI100C accepts the full range of interchangeable aluminum alloy block modules. All blocks are auto-detected on installation. The 24×1.5mL block is included as standard — additional formats are available separately.
Ideal Applications
Molecular Biology
Static enzyme digestions, heat-inactivation steps, hybridization incubations, and denaturation protocols requiring stable, precise temperatures without agitation.
Cold Sample Handling
Sub-ambient sample preservation, enzyme storage at 4°C, cold-room substitution, and cryoprotectant steps — all without ice baths or a dedicated refrigerated unit.
Protein & Biochemistry
Antibody incubations, receptor binding assays, and protein stability studies requiring isothermal holding at precise setpoints above or below ambient temperature.
What's Included
Each DBI100C ships complete and ready to use — no additional purchases required to begin your first protocol.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | DBI100C (Heat / Cool Incubator) |
| Type | Heating / Cooling Dry Block Incubator — static (no mixing) |
| Temperature Control Range | Ambient −15°C to 100°C |
| Temperature Setting Range | 0°C to 100°C |
| Recommended Ambient Temp. | 10°C to 30°C |
| Temperature Accuracy | ±0.2°C (20–40°C) / ±0.5°C (<20°C or >40°C) |
| Temperature Uniformity | ±0.5°C |
| Temperature Stability | ±0.5°C |
| Temperature Resolution | 0.1°C |
| Cooling Technology | Semiconductor Peltier — no external chiller required |
| Heating Rates | Full Power · 5°C/min · 2°C/min · 1°C/min (4 options) |
| Cooling Rates | Full Power · 2°C/min · 1°C/min · 0.5°C/min (4 options) |
| Display | 7-inch color touchscreen |
| Programs / Steps | Up to 5 sequential steps |
| Cycle Times | Up to 999 cycles |
| Timer | 0–99hr 59min 59sec |
| Calibration Points | 4 points: 10°C / 40°C / 70°C / 95°C |
| Standard Block Module | 24 × 1.5mL microcentrifuge tubes |
| Sample Capacity | 0.1mL to 50mL (depending on block module) |
| Block Detection | Automatic on installation |
| Additional Features | Pre-heating · Power failure recovery · Dry block (no liquid) |
| Max. Output Power | 300W |
| Input Voltage / Frequency | 110–220VAC, 50/60Hz |
| Dimensions (L × W × H) | 332 × 227 × 185 mm (with standard block, without lid) |
| Weight (with standard block) | <10 kg |
Warranty
Every DBI100C purchased through Surge Scientific is backed by a 2-year manufacturer's warranty covering defects in materials and workmanship from the date of purchase.
2-Year Full Warranty
Covered for 24 months from the date of purchase against any defect in materials or workmanship. Surge Scientific will repair or replace the instrument at no charge during the warranty period.
What's Covered
Semiconductor cooling system, heating element, touchscreen display, block module detection, power supply circuitry, and all internal electronic components under normal laboratory operating conditions.
Surge Scientific Warranty & Support
This instrument is sold through Surge Scientific, your trusted laboratory equipment partner. Our product specialists are available Monday–Friday for assistance. DBI100C is backed by a 2-year all-inclusive manufacturer's warranty. Contact us at info@surgescientific.com or reach out directly to our support team at 855.943.3344 for pre-sales questions, quotes, and technical assistance.
