Surge Scientific · Model AQVS-1000 · 6-Channel · Adjustable Spacing 9–19 mm · Volume 50–1000 uL
AQUA AQVS-1000
Electronic Adjustable Spacing Pipettor
Maximum Adjustable Spacing Volume · 6 uL CV at 1 mL · 6-Channel · 360° Rotatable Head · 12 Programmable Modes
Bulk reagent additions across plate formats and deep-well work demand volumes most multi-channels can't reach. The AQVS Series extends the platform to 1 mL across 6 channels with electronic spacing from 9 mm – 19 mm, holding 6 uL CV at the 1 mL nominal.
Why The AQVS-1000?
Deep-well plate workflows, large-volume cell culture additions, and bulk reagent transfers above 500 uL traditionally fall outside multi-channel scope — serological pipettes or single-channel transfers fill the gap, both of which sacrifice throughput and intra-plate consistency.
The AQVS Series closes that gap with adjustable-spacing flexibility. 6 channels driven by a single linear stepping piston deliver 16 uL accuracy and 6 uL CV at the 1 mL nominal, covering 96-well (9 mm), 48-well (13 mm), and 24-well (19 mm) plates.
9–19 mm ELECTRONIC SPACING
One-button electronic spacing control covers 96 / 48 / 24-well plates — eliminating the row-by-row manual transfers between plate formats that destroy throughput and reproducibility.
1000 uL NOMINAL ACCURACY
At full volume, the AQVS-1000 delivers 1.6% accuracy and 0.6% CV per the catalog spec, verified against DIN EN ISO 8655-2 at an ISO 17025 accredited lab.
360° ROTATABLE HEAD
The head is fully tubeless and rotates a full 360°, keeping the display visible regardless of grip angle. Faster parameter checks and improved ergonomics on long protocols.
12 MODES + 6 PROGRAMS
Forward, reverse, mix, dilute, repetitive dispense, sequential, multi-stage aspirate, stepper. Six programs save to memory — recall complex protocols with one button.
"6 channels, 9–19 mm spacing, 1.6% accuracy at 1000 uL." — The AQVS-1000 replaces a manual workflow between 96 / 48 / 24-well plates with one motorized instrument and a single calibration certificate — the kind of consistency that previously required automated liquid handlers.
Key Features
- 6-Channel adjustable-spacing configuration
- Electronic one-button tip-spacing control
- Spacing range: 9 mm – 19 mm
- Plate compatibility: 96 / 48 / 24-well plates
- Volume range: 50 – 1000 uL
- Increment resolution: 1 uL
- 1.6% accuracy at 1000 uL nominal
- 0.6% CV at 1000 uL nominal
- Color-coded volume identification — Blue band
- Tubeless, fully rotatable 360° head
- External detachable 4.2V Li-ion rechargeable battery
- 800 mAh capacity — 8 hours of operation
- ~2-hour full recharge time
- USB Type-A and Type-C charger compatibility
- Linear stepping electronic piston control
- 304 stainless steel tip cones on every channel
- 12 unique modes of operation
- Stores 6 user-defined programs in memory
- 3-speed pipetting selection (Low / Medium / High)
- Repetitive / stepper dispense mode
- 1-inch tempered LCD glass display
- Volume adjustment wheel for one-handed operation
- Soft-key programming interface
- Mini USB interface for diagnostics
- Manual tip ejection
- Universal tip cones — accept standard tip brands
- Lower section autoclavable at 121°C, 1 bar, 20 minutes
- ISO 17025 calibration certificate included
- Conforms to DIN EN ISO 8655-2 standards
Ideal Applications
DEEP-WELL PLATES
96 deep-well plate workflows for cell culture, fermentation sampling, and large-volume reagent storage.
BULK REAGENT TRANSFER
Large-volume buffer and reagent additions across plate formats with electronic spacing flexibility.
PLATE-TO-PLATE TRANSFER
Sample pooling, dilution, and reformatting workflows between plates of different formats.
Other Models in the AQVS Series
Six channels with mid-range spacing flexibility — the AQVS covers the most common plate formats in molecular biology and clinical diagnostics. The AQVS-1000 is one of 5 volume tier(s) offered in this series — same handle, same firmware, same spacing range.
Other AQUA Adjustable Spacing series with different channel counts and spacing ranges:
AQVS-1000 Accuracy & Precision
| Test Volume | Accuracy ±% | Accuracy ±uL | Precision CV ±% | Precision CV ±uL |
|---|---|---|---|---|
| 1000 uL | 1.6 | 16 | 0.6 | 6 |
| 500 uL | 3.2 | 16 | 1.2 | 6 |
| 100 uL | 16 | 16 | 6 | 6 |
Error limits in accordance with DIN EN ISO 8655-2, based on the 1000 uL nominal capacity. Per-channel calibration verified at an ISO 17025 accredited laboratory and supplied with each unit.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AQVS-1000 |
| Series | AQVS Series |
| Configuration | 6-Channel adjustable-spacing electronic pipettor |
| Number of Channels | 6 |
| Tip Spacing Range | 9 mm – 19 mm |
| Plate Compatibility | 96-well (9 mm), 48-well (13 mm), and 24-well (19 mm) plates |
| Spacing Adjustment | Electronic one-button control |
| Head Rotation | 360°, fully tubeless |
| Volume Range | 50 – 1000 uL |
| Increment | 1 uL |
| Color Code | Blue |
| Drive System | Linear stepping electronic piston control |
| Pipetting Modes | 12 (forward, reverse, mix, dilute, repetitive, stepper, etc.) |
| Memory Storage | 6 user-defined programs |
| Speed Settings | 3 (Low / Medium / High) |
| Display | 1-inch tempered LCD glass |
| Tip Cone Material | 304 grade stainless steel (per channel) |
| Tip Compatibility | Universal — accepts standard tip brands |
| Tip Ejection | Manual |
| Battery | 4.2V Li-ion, 800 mAh, detachable |
| Battery Life | 8 hours per full charge |
| Charging Time | Approximately 2 hours |
| Charger | USB Type-A and Type-C |
| USB Interface | Mini USB |
| Autoclavability | Lower section at 121°C, 1 bar, 20 minutes |
| UV Sterilization | Whole device |
| Calibration Standard | DIN EN ISO 8655-2 (ISO 17025 accredited lab) |
| Certifications | CE, ISO 9001, ISO 13485, ISO 17025 |
| Carousel Stands | Available separately |
| Warranty | 1-Year Free Replacement |
