Surge Scientific · Model TC0401005 · Mini Dry Bath — Removable Top
Mini Dry Bath Incubator
Removable Top · Non-Heated Lid
100°C Max · ±0.5°C Control · ±0.1°C Display · 5 Programs · 99h Timer · 12V Mobile-Ready
Most small-sample heating doesn't need 150°C or a footprint the size of a textbook — it needs a reliable 37°C, 42°C, 65°C, or 95°C on a bench that already has too much on it. The TC0401005 is the compact, portable, 12V-compatible mini dry bath with a removable top that accommodates any sample geometry — from 1.5 mL microtubes to 50 mL conical tubes — and five programmable protocol memories that survive the power-off cycle.
Why the Removable Top Matters
The compromise with most mini dry baths is the lid. A fixed or flip-top lid delivers better heat uniformity — but caps your tube height at roughly 2 inches, which eliminates 15 mL conicals, 50 mL conicals, and anything taller than a standard microtube. The moment a protocol needs a bigger tube, the unit becomes useless and the sample moves to a full-size dry bath that's over-engineered for the task.
The TC0401005 uses a fully removable top, so the working well opens vertically to accommodate any tube geometry the interchangeable aluminum blocks support — conical tubes, round tubes, standard centrifuge tubes. Same ±0.5°C precision, same 100°C ceiling, same programmable interface — without the height ceiling. When you need a sealed thermal environment, pop on the non-heated lid; when you need tall-tube access, lift it off.
Removable Top Design
Fully removable lid accommodates tubes of any height — 1.5 mL microtubes, 15 mL conicals, 50 mL conicals, round tubes. No height ceiling.
5 Programmable Setpoints
Store and recall five temperature + time protocols (P1–P5). Press "Prog" when powered on, pick your program, go — no menu diving.
12V Mobile-Ready
Low 12V operation voltage — runs directly from a car charger for field sampling, mobile clinics, or a travel kit. Also supports standard 100–240V mains.
Fast Ramp · Compact
Room temp to 100°C in under 15 minutes. Footprint roughly the size of a paperback — lives on crowded benches where full-size dry baths can't.
"Lift off the top. Run a 50 mL conical. Put the top back on. Run a 1.5 mL microtube." — The TC0401005's removable top is what turns a mini dry bath from a single-geometry heater into a workflow tool that handles every tube your bench sees.
Key Features
- Removable top — accommodates tall tubes
- Non-heated lid design
- Compact, portable footprint
- Max temperature 100°C
- Temperature control accuracy ±0.5°C
- Display accuracy ±0.1°C
- Heating time ≤15 min (RT to 100°C)
- LED digital display
- Simultaneous set/actual time + temp
- 3D digital wheel adjustment
- 5 programmable setpoints (P1–P5)
- Timer range 0–99h 59min
- Continuous or timed operation
- Low 12V operation voltage
- Car-charger compatible
- Dual voltage: 100–240V, 50/60 Hz
- Compatible with interchangeable blocks
- Includes 15 × 1.5 mL heating block
- Hole size Φ10.8 × 37 mm (standard block)
- Blocks available for 50 mL tubes, 15 mL tubes, round tubes
- Error code reminder
- Net weight ~1.98 lb — travel-friendly
Ideal Applications
Molecular Biology Prep
Enzyme preservation, DNA amplification prep, electrophoresis gel work, serum coagulation — protocols that live at 37°C, 65°C, or 95°C with recallable setpoints.
Mobile & Field Work
Field sampling, mobile clinics, point-of-care diagnostics, veterinary house calls — 12V operation runs directly from a car charger without mains power.
Mixed-Tube Benches
Benches where today's protocol needs a 50 mL conical and tomorrow's needs a microtube — one unit handles both without sitting idle between runs.
What's in the Box
The TC0401005 ships with a standard 15 × 1.5 mL heating block. Add blocks for other tube geometries from the catalog — 50 mL conicals, 15 mL conicals, round tubes, and cuvettes all supported.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model / SKU | TC0401005 |
| Lid Style | Removable — non-heated |
| Temperature Range | RT +5°C to 100°C |
| Temperature Control Accuracy | ±0.5°C |
| Display Accuracy | ±0.1°C |
| Heating Time (RT to 100°C) | ≤ 15 min |
| Display | LED — set/actual time + temperature |
| Control | 3D digital wheel |
| Program Memory | 5 setpoints (P1–P5) |
| Timer Range | 0–99h 59min |
| Operation Modes | Continuous or timed |
| Standard Block Included | 15 × 1.5 mL (Φ10.8 × 37 mm) |
| Interchangeable Blocks | Yes — 50 mL, 15 mL, round tubes, more |
| Operation Voltage | 12V DC · 100–240V AC, 50/60 Hz |
| Car Charger Compatible | Yes |
| Dimensions (L × W × H) | 6.45 × 4.56 × 3.85 in |
| Net Weight | ~1.98 lb |
| Safety Features | Error code reminder · Overheat protection |
