Surge Scientific · Model EP0601181 · EP-Series Single-Channel Electronic Pipette · 0.1 – 5 mL
EP-Series Electronic Pipette 0.1 – 5 mL (EP0601181)
Single-Channel · Motorized · Lithium-Ion Battery · Multi-Mode Pipetting · ISO 8655 Calibrated
0.1–5 mL high-volume electronic pipette — bulk reagent & cell culture media transfers · Single-Channel Motorized Aspiration & Dispensing · 25 µL Increment · High-Performance Motor — Eliminates Manual Pipetting Errors · Adjustable Aspirate & Dispense Speeds · Wide Choice of Pipetting Modes · Optimized Display Screen — Reduces Repeat Operations · Two-Battery Capacity (External Lithium-Ion) for Long Operation Time · Compact, Lightweight, Ergonomic · Self-Calibration · ISO 8655 Calibrated · Individual Test Certificate
The EP0601181 is the 0.1 – 5 mL EP-series single-channel electronic pipette — the motorized precision tool for labs running repetitive liquid handling at the volumes manual pipettes can't deliver consistently. High-performance motor assures high precision and consistency, eliminating the operator-fatigue variance and plunger-speed variability that breaks reproducibility on long pipetting sessions. Large-capacity two-battery configuration with easy-to-remove external lithium-ion battery for extended operation. Optimized display screen reduces repeat operations. Adjustable aspirate and dispense speeds. Wide choice of pipetting modes — pipette, dispense, mix, multi-aspirate, repeat-dispense, and reverse pipetting. Self-calibration for routine maintenance. Compact, lightweight, ergonomic body fits in either hand for fatigue-free extended use. ISO 8655 calibrated with individual factory test certificate.
Why Electronic Pipetting Eliminates the Hidden Workflow Tax of Manual Pipettes
Manual pipettes work — but they exact a hidden tax on reproducibility and ergonomics that compounds across long pipetting sessions. The variance sources are well-documented in calibration literature: operator plunger-speed variability, finger fatigue across hundreds of strokes, micro-changes in plunger blow-out timing, and the cumulative thumb-and-index-finger strain that accumulates across a busy day. By the 200th transfer, the operator is dispensing measurably differently than they were on the 1st. That accumulated drift is the hidden source of inconsistent qPCR Cq values, ELISA standard-curve scatter, and IC50 outliers that get blamed on the assay when the real culprit is the pipette.
The EP0601181 flips the math entirely. The motor takes plunger-speed variance to zero. The repeat-dispense mode turns 96 sequential aspirations into a single aspirate-then-dispense-12-times routine — 10× faster and far more consistent than manual technique. The multi-aspirate mode lets the operator pre-load multiple volumes for sequential dispensing across a complex protocol. The reverse pipetting mode handles viscous and foaming reagents (glycerol, surfactants, BSA solutions) more accurately than any manual pipette can. The optimized display screen eliminates the repeat-operation menu-fumbling that turns simple dilutions into multi-step button-presses on cheaper electronic pipettes. Add the large-capacity dual-battery configuration with easy-to-remove external lithium-ion pack for extended runtime, the self-calibration capability for routine maintenance, and the ISO 8655 individual factory test certificate shipped with each unit, and the EP-series stops being the workflow tax and becomes the workflow enabler.
0.1 – 5 mL · 25 µL Increment
0.1–5 mL high-volume range — eliminates the operator-fatigue variance of manual high-volume pipetting. Motorized 5 mL aspiration in seconds versus 15+ seconds of manual plunger pressure.
Multi-Mode Motorized
High-performance motor with adjustable aspirate and dispense speeds. Wide choice of pipetting modes — pipette, dispense, mix, multi-aspirate, repeat-dispense, reverse pipetting. The motor takes operator-variance to zero across long pipetting sessions.
Dual-Battery Lithium-Ion
Large-capacity two-battery configuration enables longer operation time. Easy-to-remove external lithium-ion battery — swap a fresh battery in seconds when one drains during long sessions, no charging-cradle delays.
ISO 8655 + Self-Calibration
Individually calibrated to ISO 8655 standards with individual factory test certificate shipped with each unit. Self-calibration capability for routine maintenance. Optimized display screen reduces repeat operations.
"Electronic precision in the 0.1 – 5 mL range. The motor takes operator-variance to zero across the long pipetting sessions where qPCR / ELISA / IC50 reproducibility is won or lost. ISO 8655 calibrated, individual test certificate."
Key Features
- Single-channel electronic pipette
- Volume range 0.1 – 5 mL
- Increment 25 µL
- High-performance motor
- Eliminates manual pipetting errors
- Compact, lightweight, ergonomic design
- Adjustable aspirate speeds
- Adjustable dispense speeds
- Multiple pipetting modes
- Pipette mode
- Dispense mode
- Mix mode
- Multi-aspirate mode
- Repeat-dispense mode
- Reverse pipetting mode
- Optimized display screen
- Reduces repeat operations
- Self-calibration capability
- Two-battery configuration
- Easy-to-remove external lithium-ion battery
- Long operation time per charge
- ISO 8655 calibrated
- Individual factory test certificate
- Universal tip cone
- Compatible with major-brand pipette tips
- Lower section autoclavable
- Suitable for repetitive liquid handling
- Suitable for cell culture / pharma R&D / molecular biology
- 1-year manufacturer warranty
Ideal Applications
Cell Culture Media Changes
T25 / T75 flask media changes, virus stock aliquoting, large-volume cell culture buffer additions — where 1–5 mL motorized transfers replace multiple smaller-pipette strokes and keep the workflow on schedule.
Bulk Buffer Prep
Bulk PBS / TBS / wash buffer preparation, working solution dilutions, environmental sample buffer additions — applications where the 1–5 mL range covers most bulk-volume bench work.
Pharma Formulation
Pharma formulation dispensing, drug screening bulk reagent additions, large-volume QC sampling — workflows where motorized 5 mL aspiration eliminates the operator-fatigue variance of manual high-volume pipetting.
What's in the Box
The EP0601181 ships ready for use with the verification documentation that ISO 8655 requires.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model / SKU | EP0601181 |
| Product Family | EP-Series Single-Channel Electronic Pipette |
| Channels | 1 (single-channel) |
| Volume Range | 0.1 – 5 mL |
| Increment | 25 µL |
| Inaccuracy at 500 µL | ±5 µL (±1.0%) |
| Inaccuracy at 2.5 mL | ±12.5 µL (±0.5%) |
| Inaccuracy at 5 mL | ±30 µL (±0.6%) |
| Imprecision at 500 µL | ±2.5 µL (±0.5%) |
| Imprecision at 2.5 mL | ±5 µL (±0.2%) |
| Imprecision at 5 mL | ±10 µL (±0.2%) |
| Pipetting Modes | Pipette · dispense · mix · multi-aspirate · repeat-dispense · reverse pipetting |
| Speed Control | Adjustable aspirate & dispense speeds |
| Display | Optimized screen — reduces repeat operations |
| Battery | External lithium-ion · two-battery capacity · easy removal |
| Operation Time | Long runtime per charge |
| Calibration Standard | ISO 8655 — individual factory test certificate included |
| Self-Calibration | Yes — routine self-calibration capability |
| Tip Cone | Universal — compatible with major-brand pipette tips |
| Tip Compatibility | 5000 µL tips |
| Lower Section | Autoclavable |
| Ergonomic Design | Compact · lightweight · ambidextrous |
| Warranty | 1-year manufacturer warranty |
