Surge Scientific · Model TMX100C · Thermal Mixer — Heating + Cooling
Thermal Mixer
Heating & Cooling · –15°C to 100°C
Semiconductor Peltier Cooling · 300–1500 RPM · 2 mm Orbital · LCD Touchscreen · Auto-Detect Modules · 99h Timer
The single unit that replaces a shaker on ice, a cold room cycle, and a dry bath. The TMX100C pairs semiconductor Peltier cooling down to –15°C with precise heating to 100°C, 2 mm orbital mixing at 300–1500 RPM, and programmable heat/cool/mix sequences on a single LCD touchscreen. Samples that need to chill during a reaction, or drop below room temperature for cold-sensitive enzyme work, stay in one unit through the whole protocol.
Why Semiconductor Cooling Changes What a Mixer Can Do
Cold-sensitive protocols traditionally force a compromise: put samples on ice with no mixing, or mix them on the bench and accept the temperature drift. Neither is honest science. Ice-bath work runs at 0°C but has zero agitation; a bench-top mixer has agitation but can't hold the sample below ambient. Anything requiring both — oligonucleotide hybridization at 4°C, cold-active enzyme kinetics, low-temperature antibody binding — ends up needing a cold room cycle that adds an hour per step.
The TMX100C uses semiconductor Peltier technology to actively chill the block below ambient — all the way to –15°C — while the brushless DC drive mixes at 300–1500 RPM. Programmable heat/cool/mix sequences let you run a protocol like "chill to 4°C, mix 10 min, ramp to 37°C, mix 30 min, ramp to 95°C" — unattended, in one unit, with auto-resumption if the power hiccups.
–15°C to 100°C Range
Semiconductor Peltier cooling drives the block down to –15°C. Heats to 100°C. Replaces the ice bath, cold room cycle, and dry bath with one programmable instrument.
300–1500 RPM · 2 mm Orbital
Brushless DC drive delivers 300–1500 RPM with a 2 mm orbital amplitude. Gentle enough for cell suspensions at 300 RPM, aggressive enough for full mixing at 1500 RPM.
Programmable Sequences
Program full heat / cool / mix sequences — chill, mix, ramp, hold, repeat. Auto-resumption after power failure picks up where the protocol left off.
Auto-Detect Modules
Interchangeable block modules with automatic detection. The unit recognizes which block is installed and loads the right calibration — no manual configuration, no wrong-block errors.
"Chill to 4°C. Mix 10 min. Ramp to 37°C. Mix 30 min. Ramp to 95°C. Unattended." — The TMX100C is what lets a protocol like that live in one instrument instead of three pieces of equipment and two transfers.
Key Features
- Temperature range –15°C to 100°C
- Semiconductor Peltier cooling technology
- Below-ambient cooling capability
- Programmable heating sequences
- Programmable cooling sequences
- Programmable mixing sequences
- Speed range 300–1500 RPM
- 2 mm orbital mixing amplitude
- Brushless DC motor — low-noise, maintenance-free
- Large LCD touchscreen display
- Intuitive navigation and programming
- Auto-detect module recognition
- Interchangeable aluminum blocks
- Auto-resumption after power failure
- Microprocessor temperature control
- Superior temperature stability and uniformity
- Timer range 0–99h 59min
- Continuous or timed operation
- RT to 100°C heating time ≤ 15 min
- Compact 220 × 300 × 170 mm footprint
- Dual voltage: 100–240V, 50/60 Hz
- Blocks sold separately — 30+ options
Ideal Applications
Cold-Sensitive Protocols
Oligonucleotide hybridization at 4°C, cold-active enzyme kinetics, antibody binding assays, and cold-room work that demands active mixing during chilled incubation.
Multi-Temperature Protocols
Ligation (4°C), digestion (37°C), heat-kill (65°C), denaturation (95°C) — run the entire sequence on one unit, unattended, with auto-resumption.
Sample Preservation
Hold precious samples at 4°C with gentle mixing for protein stability, cell suspension work, and overnight storage during a multi-day protocol.
What's in the Box
The TMX100C ships ready to run — heating blocks are sold separately. The auto-detect system recognizes any block in the 30+ catalog, so swap between microtubes, 15 mL tubes, PCR plates, or cuvettes without reconfiguring the unit.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model / SKU | TMX100C |
| Function | Thermal mixing — heating & cooling |
| Temperature Range | –15°C to 100°C |
| Cooling Technology | Semiconductor (Peltier) |
| Heating Time (25°C to 100°C) | ≤ 15 min |
| Speed Range | 300–1500 RPM |
| Orbital Amplitude | 2 mm (horizontal) |
| Motor Type | Brushless DC — low-noise, maintenance-free |
| Control | Microprocessor · LCD touchscreen |
| Display | Large LCD — temp + speed + status |
| Programming | Programmable heat / cool / mix sequences |
| Module Detection | Automatic — auto-detects interchangeable blocks |
| Power Failure Recovery | Auto-resumption |
| Timer Range | 0–99h 59min |
| Operation Modes | Continuous or timed |
| Dimensions (W × D × H) | 220 × 300 × 170 mm |
| Weight | 7.9 kg |
| Voltage / Frequency | 100–240V, 50/60 Hz |
| Heating Blocks Included | No — sold separately |
Surge Scientific Warranty & Support
This instrument is sold through Surge Scientific, your trusted laboratory equipment partner. Our product specialists are available Monday–Friday for assistance. The TMX100C is backed by a 2-year all-inclusive manufacturer's warranty. Contact us at info@surgescientific.com or reach out directly to our support team at 855.943.3344 for pre-sales questions, module selection, custom block quotes, and technical assistance.
